DBM-6030DTC Auto CNC Drilling Tapping Cutting machine
Product Information
- This auto CNC drilling machine With multi-function integrating drilling, tapping, and cutting.
- Adopts a high-precision mechanical spindle, and the three spindles can be equipped with 3 tools to process different processes at the same time.
- Feeding automatically, saving loading and unloading time.
- The open structure can be used for multi-station processing, without stopping the material change cycle processing.
- Detected and compensated corrected by the laser interferometer imported from the United States (API).
| Model NO. | DBM-6030DTC | ||||
| Route | X-axis | 6000mm | |||
| Y-axis | 300mm | ||||
| Z-axis | 200mm | ||||
| Main spindle | Speed | 1500～24000rpm(According requirements) | |||
| Tool handle type | ER20 | ||||
| Power | 0.55kw～3.0kw(According requirements) | ||||
| Moving speed | X-axis | 30m/min-60m/min | |||
| Y-axis | 25m/min | ||||
| Z-axis | 25m/min | ||||
| Processing capacity | Drilling | 1～20mm | |||
| Tapping | M2-M14 | ||||
| Chamfering | 1～20mm | ||||
| Tool magazine | Manual change | ||||
| Repeatability | ±0.02mm | ||||
| Cutting accuracy | ±0.05mm | ||||
| Programmatically | CAD file import/computer programming/teaching programming / manual programming | ||||
| System program memory | About 10000 pcs | ||||
| System external signal control | Support | ||||
| Working voltage | AC 220V/50HZ | ||||
| Dimension | 8200mm*1550mm*2000mm | ||||
| Weight | About 4500kg | ||||
