DBM-1825 Dual table five axis CNC machine
Product Information
Five-Axis Machining Center: Our state-of-the-art five-axis machining center is engineered for precision and versatility, capable of processing a wide array of non-metallic materials including wood, fiberglass, plastic, PVC, and gypsum.
Multi-Angle Processing: With the ability to machine at any angle, this equipment ensures exceptional accuracy and detail for complex designs. Whether you’re creating intricate furniture, detailed statues, or custom molds, our machine delivers flawless results every time.
Versatile Applications: Perfect for various projects, our machining center excels in:
- Furniture Production: Craft beautifully designed pieces with precision and efficiency.
- Statue Creation: Achieve intricate details and smooth finishes for stunning sculptures.
- Mold Fabrication: Create precise molds for various applications, enhancing production capabilities.
- Handicrafts: Ideal for artisans seeking to elevate their craft with high-quality machining.
- Plastic Shape Cutting: Effortlessly cut and shape plastic materials to meet specific project requirements.
| Model NO. | DBM-1825 |
| X-axis, Y-axis, Z-axis | 3700mm, 1650mm, 900mm |
| A-axis | +110° to -110° |
| C-axis | ±540° |
| Control System | Taiwan brand SYNTEC control system |
| Compatible files | G/M code/NC program |
| Tool capacity | 4 pcS |
| Tool magazine | Optional |
| Lubrication system | Automatic positive displacement refueling pump |
| Structure | High-strength steel structure welding frame |
| X/Y/Z structure | X/ Y / Z-axis precision ball screw |
| Work table structure | T-profile aluminum profile/vacuum adsorption table |
| Servo Motor | Japan Yaskawa AC servo motor |
| Guide Rail/Screw rod | Taiwan PMI Guide Rail/Taiwan TBI |
| Spindle power | 3.7-10kw |
| Spindle speed | 0-24000rpm, Liquid-cooled/air-cooled spindle |
| X/Y/Z positioning accuracy | ±0.05mm |
| X/Y/Z movement speed | 40/40/20 m/min |
| Feeding rate | 15m/min |
| Power | AC380V/50HZ |
| Air pressure | 6bar |
| Dimension | 3650MM*4810MM *3738MM |
| Weight | About 3500kg |
